Description
| Detector | |
| Detector | Uncooled VOX sensor |
| Resolution | 256×192 |
| Temperature Measurement | |
| Measurement range | 33°C~42°C |
| Accuracy | ±0.3℃(With blackbody)±0.5℃(Without blackbody） |
| Detection Distance | 0.5~3.5m |
| Installation Height | 1.8m |
| Flux | >100 people/minute |
| High Temperature Alarm | Support |
| Visible Camera | |
| Image Sensor | Sony IMX307 |
| Resolution | 2.0MP,1920×1080 |
| Video Compression | H.265/H.264 |
| Lens | 6mm |
| WDR | Support |
| Interface | |
| Interface | 10M/100M Ethernet, RJ45 Port, |
| RS485 | Support |
| HDMI | Support |
| Alarm Intput&Output | Support |
| Audio Input&Output | Support, Built-in Speaker |
| Storage | EMMC Method |
| Network | |
| Protocols | TCP/IP, UDP, ICMP, IGMP, DHCP, RTSP |
| Interface | 10M/100M Ethernet, RJ45 Port, |
| VMS | Support |
| General | |
| Working Temperature | -10°C~60°C (With Blackbody) |
| Storage temperature | -20°C~60℃ |
| Humidity | 5%~95%, Non-condensing |
| Power Supply | DC 12 V/2A |
| Working Environment | Indoor, No Wind |
| Installation | Tripod (Optional) |
| Dimensions | 115*187*75mm |
